WF6000
[I&C Technology]
Overview
- Single-Chip Wi-Fi integrated PHY/MAC/RF/PA for “Internet of Things(IoT)” market
- IEEE 802.11 a/b/g/n with 1 Rx 1 Tx, enhanced MAC, QoS, Security features
- Easy system integration and minimal use of host resources
- Flexibility to implement network and security protocols stack
PHY/MAC Features
- Compliant with IEEE 802.11 a/b/g and 802.11n
- Data-Rate up to 72Mbps (20MHz)
- Supported features
- Short Guard-Interval
- STBC(2x1) and RIFS Rx
- Legacy/Mixed/Greenfield
- 802.11h DFS, TPC
- MSDU and A-MPDU
- Defragmentation / Block Ack Agreement
- U-APSD
(Unscheduled Automatic Power-Saving Delivery)
Advanced Technologies
- DPD for the controlled Tx Quality with low power consumption
- MCS-Based Controllable CFR
(Maximum Reduction PAPR is 6.8dB)
- Tracking Ability of more than 50ppm CFO by DCXO
Ultimate Digital Baseband PHY Rx Performance
- Unrealistic Implementation Loss: Only 1dB SNR loss 10% PER, AWGN, Comparisons with Ideal Performance
- Fully Digital-Controlled Fast AGC
(1dB Step Size and 100dB Dynamic Range)
- Precise 11n/11b Signal Detector for -99dBm sensitivity
- SNR-Maximized Symbol Synchronization Techniques
- RPE for Compensating Residual Frequency and Time Offsets
- Smart Smoothing Channel Estimations
- Optimized Equalization and LLR Quantization
- Low Complexity Hybrid Architecture Viterbi Decoder
- 11b DSSS/CCK Receiver with Channel Matched Filters and Adaptive Equalizers
(-1usec to 0.8usec Residual ISI)
- RSSI/SNR Measurement and Report
Host & Other Interface Features
- SDIO 2.0 4-bit/1-bit & SPI Slave Interface with an Advanced Proprietary Host DMA Accelerator
- Serial Flash Interface
- Standalone UART Interface
- I2S master/slave for audio interface
- I2C master/slave
- SPI master/slave
- IR Remote Control
- General-Purpose ADC
- Other Peripherals – GPIO, PWM
Power Supply Features
- One DC-DC Buck
- LDOs
- 1.2V/1.1V
Package
- 7.0 mm x 7.0 mm, QFN, 60-pins RF Calibrations
- I/Q mismatch, LO leakage, Filter Bandwidth and DC Offset
- Self-Calibrations without Any External Devices or Equipment
- QoS Supports
- Compliant with IEEE 802.11e QoS Enhancements
- Supports up to 4 ACs
- Supports up to 4 Block Ack Agreements
- Supports WMM and WMM Power-Save including
- U-APSD
Security Supports
- Compliant with IEEE 802.11i and IEEE 802.1X Security Standard
- Supports WEP, TKIP and AES Data
- Encryption/Decryption with Hardware Acceleration
- Supports WEP, WPA and WPA2 security configurations
- Hardwired security engine for contents protection
MD5/SHA1/SHA2/SHA3/DES/3-DES/AES/ARIA
RF Features
- Operates in 2.4 ~ 2.5 GHz, 4.9 ~ 5.85 GHz Frequency Bands with 20MHz Bandwidth
- RF and Power-Amp Integrated with MAC/PHY
- 2.4GHz Rx Sensitivity -75dBm at 11n HT20 MCS7
- 2.4GHz Tx Output Power
- 21dBm at 11b DSSS 1Mbps
- 17dBm at 11n HT20 MCS7
5GHz Rx Sensitivity -74dBm at 11n HT20 MCS7
5GHz Tx Output Power
- 16.5dBm at 11n HT20 MCS7
Embedded Processor Features
- 160 MIPS RISC Processor integrated
- 128KB Code and 512KB Data Memory
- 32KB Instruction Cache and 8KB Data Cache Memory
- Supports MAC Code without External CPU
- IoT Protocol Feature
Https/MQTT/OneM2M/LWM2M/GMMP/SEP2.0/Alljoyn/Weave/GCM
